Swimming Pool Heat Pumps

Swimming Pool Heat Pumps are the most popular pool heating method. We sell standard heat pumps with the latest R32 Gas and the latest Inverter Heat Pumps. Inverter Swimming Pool Heat Pumps offer substantial savings with COP of upto 15. Inverter Heat Pumps are also Ultra Quiet. World Of Pools only sells the heat pumps that we have checked and tested ourselves. We stock Hydropro, Waterco, Calorex, DanthermHeatseeker, Rio & Garden Pac. Norsup full inverter heat pumps are available from our retail shop.  Call us for more information, we know our heat pumps inside out, trust their reliability and can recommend with conviction which will be best for you and how you use your pool.
  • 2024 Poolstyle Inverter Heat Pumps - Heat & Cool 9°C to 40°C
  • Auto/Boost/Smart & ECO Functions
  • Variable Speed Inverter - With Built In WIFI
  • Inverter Reduces Running Costs - COP Up To 10.6
  • Seasonal COP of 6.69 - Massive SCOP
  • Works Even When Ambient Air Is 0°C & Heats Water Up To 40°C
  • In Stock For Same Day Shipping
  • 5 Year Spiral Heat Exchanger Warranty & 2 Year Parts Only Warranty

DELIVERY: We aim to send Poolstyle Inverter Heat Pumps out on a next working day service but all standard deliveries will be within 5 working days

RETURNS:

Poolstyle Inverter Swimming Pool Heat Pumps can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

PRODUCT INFO:



2024 Poolstyle Inverter Swimming Pool Heat Pumps

, apart from being one of the quietest Heat Pumps available, they are probably the best value Inverter Swimming Pool Heat Pump available, with 2024 models come with built in WIFI & Heating & Cooling, from 40°C down to 9°C. These Inverter Heat Pumps are 7 times quieter than standard heat pumps offering higher COP up to 10.6, with a Seasonal COP of 6.69, and they can even work down to -10 degrees C ambient air temperature and heat water up to 40°C.



 Manufactured for PoolCorp, a Worldwide pool company with around £3Billion per year turnover, they are made to the highest specification and backed by the largest pool company in the World.

The 2024 Poolstyle Inverter has built in WiFi, allowing Real-Time monitoring and simple control of the heat pump, where ever you are.

Poolstyle Inverter Swimming Pool Heat Pump 9kw & 11kw Features :

  • Can be fitted with a 13amp Plug
  • Heat & Cool The Water
  • Proven reliability
  • Quiet Operation
  • Titanium heat exchanger
  • High efficiency compressor
  • Quick and easy installation
  • ABS Casing
  • Very quiet operation
  • Reverse cycle defrost
  • Soft start typically lowers start-up amps by at least 50%

If you would like help choosing which Poolstyle Step Inverter Heat Pump is most suitable for your swimming pool please call us on 01322 554 870. We will be more than happy to help.

 Model      9kW 11.5kW 18.5kW
Performance condition: Ambient temperature (DB/WB) 27c/24.3c, Water Inlet/Outlet Temperature 26c/28c


Heating Capacity kW 1.8-9.5 3.5-15.3 4.78-25.3
Consumed Power kW 0.124-1.46 0.243-2.41 0.34-4.3
COP w/w 14.5-6.5  14.4-6.35 14.1-5.88
Boost Mode Heating Capacity kW/COP 9.5kW 6.5 COP 15.3kW 6.35 COP 25.3kW 5.88 COP
Smart Mode Heating Capacity kW/COP 7.8kW 7.52 COP 11.55kW 7.68 COP 20.4kW 7.6 COP
Silent Mode Heating Capacity kW/COP 3.5kW 12.2 COP 7.35kW 10.62 COP 12.3kW 10.2 COP
Performance condition: Ambient temperature (DB/WB) 15c/12c, Water Inlet/Outlet Temperature 26c/28c
Heating Capacity kW 1.5-7.9 2.95-11.15 3.8-17.1
Consumed Power kW 0.194-1.491 0.386-2.226 0.49-3.47
COP w/w 7.73-5.3 7.64-5.01 7.76-4.93
Boost Mode Heating Capacity kW/COP 7.9kW 5.3 COP 11.5kW 5.01 COP 17.1kW 4.93 COP
Smart Mode Heating Capacity kW/COP 6.1kW 5.95 COP 8.65kW 5.72 COP 11.5kW 5.84 COP
Silent Mode Heating Capacity kW/COP 2.5kW 6.92 COP 5.55kW 6.55 COP 8.3kW 6.52 COP
Operating Air Temperature -10c to 43c
Heating Temperature range 9c to 40c
Cooling Temperature range 8c to 35c
Recommended pool volume 20-40m3 30-60m3 55-90m3
Max Power output 1.75kW 3.2kW 4.5kW
Max current 7.95A 14.5A 19.5A
Air volume m3/h 900 1300 1600
Sound Pressure 33-46dB 34-48dB 35-55dB
Water Flow volume 4.1m3/h 6.6m3/h 10.8m3/h
Water pipe connection 50mm
Hydropro P12 Swimming Pool Heat Pump
  • Hydropro P12 Swimming Pool Heat Pumps
  • Complete with 6m Plug and Play Cable Kit
  • In Stock For Same Day Despatch
  • Sale Prices - Cheapest Online Or We Match Price
  • Suitable For All Year Use If Sized Correctly - Call For Advice
  • 2 Year Parts & Labour Warranty

DELIVERY: Hydropro P12 Swimming Pool Heat Pumps are sent out via a specialist haulier. Delivery takes between 1-3 days.



RETURNS: This product can be returned in original packaging, suitable for resale, within 14 days from date of delivery. When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

PRODUCT INFO:



Hydropro P12/32 swimming pool heat pumps

are suitable for swimming pools up to 50m3 during the main summer months, slightly less if starting in April or the beginning of May. As the Hydropro P12 Heat Pump is one of the newest ranges of Swimming Pool Heat Pumps available they are supplied with R32 Gas

Comes complete with Plug and Play Cable Kit that needs to be installed by a competent person so perfect for inground and above ground pools

As the Hydropro P14 Heat Pump will function even when the ambient air temperature is as low as 0° Celcius they can be used all year round, but with reduced C.O.P. and output. To function correctly the heat pump will need to be sized correctly. As a very rough guide, it is suggested to at least double the Ideal Size, but it is advisable if you call us on 01322 554 870 to ensure suitability.

Hydropro P12 Heat Pump - Summer Use

Ideal Size Pool 24ft x 12ft x 4ft Deep

Maximum Pool Size 24 ft x 12ft x 5ft Deep

To see other sizes of hydropro heat pumps click here. Full Range Of Heat Pumps

For help and advice call 01322 554 870



Hydropro P12/32 Heat Pump Data



heating power input

1.95 kW

heating capacity (A27/W27)

11.5 kW

heating capacity (A15/W26)

6.5 kW

maximum volume of pool

with good insulation

50m3 /

50,000 litres

coefficient (C.O.P.)  at A27/W27

5.90

coefficient (C.O.P.)  at A15/W25

4.59

compressor

rotary

refrigerant

R32

fan quantity

1

fan power input

90

fan rotate speed

850 RPM

fan direction

Horizontal

noise level (10 metres)

43 dB (A)

water connection

50mm

nominal water flow

4.5 m/h3

dimensions (L/W/H)

100cm / 39cm / 60cm

Type C or D Breaker Size 15 amp
Hydropro P20 Swimming Pool Heat Pump - R32 Gas
  • Hydropro P 20 Swimming Pool Heat Pump
  • New R32 Gas
  • Latest Model
  • Suitable for Pools up to 70,000 litres
  • Same Day Dispatch Fast Delivery
  • 2 Year Parts & Labour Warranty

DELIVERY: We aim to send all products out on a next working day service but all standard deliveries will be within 5 working days

RETURNS: The Hydropro P20 Heat Pump can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

PRODUCT INFO:



Hydropro P 20 Swimming Pool Heat Pumps

are ideal for swimming pools up to 70m3 during the main summer months, slightly less if starting in April or the beginning of May.

Hydro Pro P20 Heat Pump

Ideal Size Pool - 30ft x 15ft x 4ft Deep

Maximum Size Pool - 30ft x 15ft x 5ft Deep

The Hydropro P20 will produce roughly 20kw of energy at 27 degrees air temp and nearly 14kw at 15 degrees while only drawing 2.87kw, making it an effective cost saving heating solution for your swimming pool. The Hydropro P20 contains the latest R32 gas making it more enviromentally freindly and better performing.These heat pumps need to have good ventilation and shuould be postition in an outdoor free to allow the ambient air to be drawn in and free to allow the cold air to escape

As an example the ideal size pool for this hydropro P20 swimming pool heat pump is a 30ft x 15ft that is 4ft deep swimming pool, although this is just a basic guide.

For help and advice call 01322 554 870


Hydropro P20 Heat Pump Data



Power Input

2.87 kW

Heating Capacity (A27/W27)

19.5 kW

Heating Capacity (A15/W26)

13.8 kW

Maximum Volume of Pool

With Good Insulation

70m3 / 70,000 litres

Running Current

12.8 Amps

Power Supply Type C or D breaker

35 AMPS

Coefficient (C.O.P.)  at A27/W27

6.3

Coefficient (C.O.P.)  at A15/W25

4.81

Compressor

Rotary

Refrigerant

R32

Fan Quantity

1

Fan Power Input

2000

Fan Rotate Speed

850 RPM

Fan Direction

Horizontal

Noise Level (10 metres)

57 dB (A)

Water Connection

50mm

Minimum Water Flow

6.8 m3/h

Dimensions (L/W/H)

115cm / 47cm / 87cm



Hydropro P20 Swimming Pool Heat Pump - R32 Gas
  • Hydropro P20 Swimming Pool Heat Pump
  • New R32 Gas
  • Latest Model
  • Suitable for Pools up to 70,000 litres
  • Same Day Dispatch Fast Delivery
  • 2 Year Parts & Labour Warranty

DELIVERY: We aim to send all products out on a next working day service but all standard deliveries will be within 5 working days

RETURNS: The Hydropro P20 Heat Pump can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

Returns Address: Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870

When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

PRODUCT INFO:

Hydropro P20 Swimming Pool Heat Pumps

are ideal for swimming pools up to 70m3 during the main summer months, slightly less if starting in April or the beginning of May.

Hydro Pro P20 Heat Pump

Ideal Size Pool - 30ft x 15ft x 4ft Deep

Maximum Size Pool - 30ft x 15ft x 5ft Deep

The Hydropro P20 will produce roughly 20kw of energy at 27 degrees air temp and nearly 14kw at 15 degrees while only drawing 2.87kw, making it an effective cost saving heating solution for your swimming pool. The Hydropro P20 contains the latest R32 gas making it more enviromentally freindly and better performing.These heat pumps need to have good ventilation and shuould be postition in an outdoor free to allow the ambient air to be drawn in and free to allow the cold air to escape

As an example the ideal size pool for this hydropro P20 swimming pool heat pump is a 30ft x 15ft that is 4ft deep swimming pool, although this is just a basic guide.

For help and advice call 01322 554 870


Hydropro P20 Heat Pump Data



Power Input

2.87 kW

Heating Capacity (A27/W27)

19.5 kW

Heating Capacity (A15/W26)

13.8 kW

Maximum Volume of Pool

With Good Insulation

70m3 / 70,000 litres

Running Current

12.8 Amps

Power Supply Type C or D breaker

35 AMPS

Coefficient (C.O.P.)  at A27/W27

6.3

Coefficient (C.O.P.)  at A15/W25

4.81

Compressor

Rotary

Refrigerant

R32

Fan Quantity

1

Fan Power Input

2000

Fan Rotate Speed

850 RPM

Fan Direction

Horizontal

Noise Level (10 metres)

57 dB (A)

Water Connection

50mm

Minimum Water Flow

6.8 m3/h

Dimensions (L/W/H)

115cm / 47cm / 87cm



  • Mr Perfect InverPad Inverter Swimming Pool Heat Pump
  • 5 Year Parts Only Warranty
  • Option To Upgrade To 3 Year Or 5 Year Parts & Labour Warranty
  • LCD Screen & App Controlled
  • New Technology Means Quietest Swimming Pool Heat Pump Ever
  • 2024 Models 20 Times Quieter Than Most Heat Pumps
  • Inverter Heat Pump Technology - Complete Variable Speed
  • Turbo Fan With Side Venting Increases COP & Reduces Noise
  • COP up to 16 - Operates Down To -15° C - R32 Gas With Soft Start
  • 12 Year Titanium Heat Exchanger & Mitsubishi Compressor Warranty

DELIVERY: Mr Perfect InverPad Inverter Swimming Pool Heat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

RETURNS: Mr Perfect InverPad Inverter Swimming Pool Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

.

When a returned Mr Perfect InverPad Inverter Swimming Pool Heat Pump is received back into our warehouse our returns department confirms that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occur.

PRODUCT INFO:



Mr Perfect InverPad Inverter Swimming Pool Heat Pumps

are the quietest Swimming Pool Heat Pump in the UK in 2024.



In 2024 the UK's quietest heat pumps are the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps. All models have WIFI built in, and Mr Perfect Inverter Heat Pumps are 20 times quieter than other heat pumps thanks to their nearly silent fan and compressor.

For this changing world, with rising energy costs, the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps provide "All Year Round" heating by operating in temperatures as low as -15 degrees Celsius and heating water to 40 degrees Celsius whilst, at times, only using 7% of the electricity you would have used with an electric heater and 30% when compared to a standard On/Off heat pump.

With Mr Perfect InverPad Inverter Swimming Pool Heat Pumps, you can enjoy both quiet operation and all year-round heating.

Even if you don't require year-round heating, having a swimming pool heat pump that can operate with an efficient COP at low temperatures means that the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps will enable you to quickly and affordably heat an outdoor pool at the start and end of the season, which are typically the hardest times to keep the pool warm.

The Mr Perfect InverPad Inverter Swimming Pool Heat Pumps are the most up to date Swimming Pool Heating because they are loaded with the best quality components and innovative fan and evaporator design, that offers higher COP and increased effectiveness, while being even quieter than any other pool heat pump in the UK.

The Mr Perfect InverPad Inverter Swimming Pool Heat Pumps will be able to provide you with a 52 Week All-Year Round Swimming Season or just an Extended Season, depending on which size of Heat Pump you buy. So, if you require an Ultra Quiet, Super-Efficient heat pump for 12 month swimming use or only to extend the Summer season call us on 01322 554 870 to help you decide which Mr Perfect InverPad Inverter Swimming Pool Heat Pumps is best suited for your needs.

You may not require your pool heated in low temperatures but having a heat pump that will not freeze up or cut off at 10° or 5° degrees can be a huge benefit, as April and October mornings may be a lot cooler, even though you may not be using your pool you will still need to heat it to be able to use your pool in the afternoons when it is sunny and warm.

If you require help sizing your Mr Perfect InverPad Inverter Swimming Pool Heat Pumps for your pool please call us on 01322 554 870

WHAT'S INCLUDED WITH MR PERFECT SWIMMING POOL HEAT PUMP

  • Dark Grey Aluminium Casing with detachable grille(s) for evaporator cleaning.
  • Built-in Wi-Fi (2.4g).
  • 2m Prewired 6mm flexible electric cable.
  • 32AMP IP61 Isolator Switch.
  • 32AMP IP67 Waterproof quick disconnect for easy cleaning and winterising.
  • 40mm Rubber Anti-Vibration Feet
  • Drainage Kit.
  • Canvas Winter Cover.
  • Kerbside Pallet Delivery.


Garden Pac Inverter Heat Pump PDF Downloads

Mr Perfect Inverpad Inverter Heat Pump With Wi-Fi Brochure



Model

Mr Perfect MPC220  22KW

Mr Perfect MPC270   27KW

Mr Perfect MPC320  32KW

Mr Perfect MPC3203   32KW  3Phase Mr Perfect MPC4203    41KW  3Phase
Operating air temperature (˚C)
-15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C
Advised pool volume (m3) *
45-85 50-95 60-120 60-120 85-160
Air 27°C / Water 27°C / Humidity 80%



Heating capacity (kW) turbo mode
22.5kw 26.5kw 31.5kw 31.5kw 40.5kw
Heating capacity (kW) perfect mode 18kw 20.6kw 26.8kw 26.8kw 34.5kw
COP range 15.5~7.4 15.2~7.3 16.0~7.2 15.8~7.2 16.0~7.0
Average COP at 50% Speed 11.8 11.5 11.6 11.6 11.5
Air 15°C / Water 26°C / Humidity 70%
Heating capacity (kW) turbo mode 15.0 18.0 21.8 22.1 29.0
Heating capacity (kW) perfect mode 12.6 14.4 18.0 18.0 23.9
COP range 7.0 6.8 6.9 7.0 7.0
Power supply 230V 1Ph 230V 1Ph 230V 1Ph 400V 3Ph 400V 3Ph
Sound level at 1m dB(A) * 39.5~49.8 39.8~50.2 40.3~50.8 40.5~50.9 40.6~51.3
Sound level by 50% speed 1m dB(A) * 43.0 43.1 45.1 45.6 45.7
Sound level at 10m dB(A) * 19.5~29.8 19.8~30.2 20.3~30.8 20.5~30.9 20.6~31.3
Rated input power (kW) 0.45~3.33 0.54~4.00 0.59~4.36 0.60~4.42 0.78~5.80
Input power at 50% Speed (kW) 0.90 1.06 1.30 1.29 1.71
Rated input current (A) 1.96~14.48 2.35~17.39 2.56~18.96 0.86~6.41 1.13~8.41
Advised water flux (m3/h) 6~9 8~10 10~12 10~12 12~18
Water connection (inch) 1.5 1.5 1.5 1.5 1.5
Net dimensions LxWxH (mm)

980 x

504 x

756

1135 x

514 x

756

1029 x

512 x

1107

1029 x

512 x

1107

1139 x

512 x

1106

Net weight (kg) 91 114 136 142 160


  • Mr Perfect InverPad Inverter Swimming Pool Heat Pump
  • 3-Year On-Site Labour & 5 Year Parts Warranty
  • Option To Upgrade To 5 Year Parts & Labour Warranty
  • LCD Screen & App Controlled
  • New Technology Means Quietest Swimming Pool Heat Pump Ever
  • 2024 Models 20 Times Quieter Than Most Heat Pumps
  • Inverter Heat Pump Technology - Complete Variable Speed
  • Turbo Fan With Side Venting Increases COP & Reduces Noise
  • COP up to 16 - Operates Down To -15° C - R32 Gas With Soft Start
  • 12 Year Titanium Heat Exchanger & Mitsubishi Compressor Warranty

DELIVERY: Mr Perfect InverPad Inverter Swimming Pool Heat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

RETURNS: Mr Perfect InverPad Inverter Swimming Pool Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

.

When a returned Mr Perfect InverPad Inverter Swimming Pool Heat Pump is received back into our warehouse our returns department confirms that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occur.

PRODUCT INFO:



Mr Perfect InverPad Inverter Swimming Pool Heat Pumps, with 3-Year On-Site Labour Warranty

, are the quietest Swimming Pool Heat Pump in the UK in 2024.



In 2024 the UK's quietest heat pumps are the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps. All models have WIFI built in, and Mr Perfect Inverter Heat Pumps are 20 times quieter than other heat pumps thanks to their nearly silent fan and compressor.

For this changing world, with rising energy costs, the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps provide "All Year Round" heating by operating in temperatures as low as -15 degrees Celsius and heating water to 40 degrees Celsius whilst, at times, only using 7% of the electricity you would have used with an electric heater and 30% when compared to a standard On/Off heat pump.

With Mr Perfect InverPad Inverter Swimming Pool Heat Pumps, with 3-Year On-Site Labour Warranty and a 5 Year Parts Warranty, you can enjoy both quiet operation and all year-round heating with the knowledge you are covered in the unlikely event anything goes .

Even if you don't require year-round heating, having a swimming pool heat pump that can operate with an efficient COP at low temperatures means that the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps will enable you to quickly and affordably heat an outdoor pool at the start and end of the season, which are typically the hardest times to keep the pool warm.

The Mr Perfect InverPad Inverter Swimming Pool Heat Pumps are the most up to date Swimming Pool Heating because they are loaded with the best quality components and innovative fan and evaporator design, that offers higher COP and increased effectiveness, while being even quieter than any other pool heat pump in the UK.

The Mr Perfect InverPad Inverter Swimming Pool Heat Pumps will be able to provide you with a 52 Week All-Year Round Swimming Season or just an Extended Season, depending on which size of Heat Pump you buy. So, if you require an Ultra Quiet, Super-Efficient heat pump for 12 month swimming use or only to extend the Summer season call us on 01322 554 870 to help you decide which Mr Perfect InverPad Inverter Swimming Pool Heat Pumps is best suited for your needs.

You may not require your pool heated in low temperatures but having a heat pump that will not freeze up or cut off at 10° or 5° degrees can be a huge benefit, as April and October mornings may be a lot cooler, even though you may not be using your pool you will still need to heat it to be able to use your pool in the afternoons when it is sunny and warm.

If you require help sizing your Mr Perfect InverPad Inverter Swimming Pool Heat Pumps for your pool please call us on 01322 554 870

WHAT'S INCLUDED WITH MR PERFECT SWIMMING POOL HEAT PUMP

  • 3 Year On-Site Labour Warranty With A 5-Year Parts Warranty
  • Dark Grey Aluminium Casing with detachable grille(s) for evaporator cleaning.
  • Built-in Wi-Fi (2.4g).
  • 2m Prewired 6mm flexible electric cable.
  • 32AMP IP61 Isolator Switch.
  • 32AMP IP67 Waterproof quick disconnect for easy cleaning and winterising.
  • 40mm Rubber Anti-Vibration Feet
  • Drainage Kit.
  • Canvas Winter Cover.
  • Kerbside Pallet Delivery.


Garden Pac Inverter Heat Pump PDF Downloads

Mr Perfect Inverpad Inverter Heat Pump With Wi-Fi Brochure



Model

Mr Perfect MPC220  22KW

Mr Perfect MPC270   27KW

Mr Perfect MPC320  32KW

Mr Perfect MPC3203   32KW  3Phase Mr Perfect MPC4203    41KW  3Phase
Operating air temperature (˚C)
-15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C
Advised pool volume (m3) *
45-85 50-95 60-120 60-120 85-160
Air 27°C / Water 27°C / Humidity 80%



Heating capacity (kW) turbo mode
22.5kw 26.5kw 31.5kw 31.5kw 40.5kw
Heating capacity (kW) perfect mode 18kw 20.6kw 26.8kw 26.8kw 34.5kw
COP range 15.5~7.4 15.2~7.3 16.0~7.2 15.8~7.2 16.0~7.0
Average COP at 50% Speed 11.8 11.5 11.6 11.6 11.5
Air 15°C / Water 26°C / Humidity 70%
Heating capacity (kW) turbo mode 15.0 18.0 21.8 22.1 29.0
Heating capacity (kW) perfect mode 12.6 14.4 18.0 18.0 23.9
COP range 7.0 6.8 6.9 7.0 7.0
Power supply 230V 1Ph 230V 1Ph 230V 1Ph 400V 3Ph 400V 3Ph
Sound level at 1m dB(A) * 39.5~49.8 39.8~50.2 40.3~50.8 40.5~50.9 40.6~51.3
Sound level by 50% speed 1m dB(A) * 43.0 43.1 45.1 45.6 45.7
Sound level at 10m dB(A) * 19.5~29.8 19.8~30.2 20.3~30.8 20.5~30.9 20.6~31.3
Rated input power (kW) 0.45~3.33 0.54~4.00 0.59~4.36 0.60~4.42 0.78~5.80
Input power at 50% Speed (kW) 0.90 1.06 1.30 1.29 1.71
Rated input current (A) 1.96~14.48 2.35~17.39 2.56~18.96 0.86~6.41 1.13~8.41
Advised water flux (m3/h) 6~9 8~10 10~12 10~12 12~18
Water connection (inch) 1.5 1.5 1.5 1.5 1.5
Net dimensions LxWxH (mm)

980 x

504 x

756

1135 x

514 x

756

1029 x

512 x

1107

1029 x

512 x

1107

1139 x

512 x

1106

Net weight (kg) 91 114 136 142 160


  • Mr Perfect InverPad Inverter Swimming Pool Heat Pump
  • 5-Year On-Site Part & Labour Warranty
  • Option To Upgrade To 5 Year Parts & Labour Warranty
  • LCD Screen & App Controlled
  • New Technology Means Quietest Swimming Pool Heat Pump Ever
  • 2024 Models 20 Times Quieter Than Most Heat Pumps
  • Inverter Heat Pump Technology - Complete Variable Speed
  • Turbo Fan With Side Venting Increases COP & Reduces Noise
  • COP up to 16 - Operates Down To -15° C - R32 Gas With Soft Start
  • 12 Year Titanium Heat Exchanger & Mitsubishi Compressor Warranty

DELIVERY: Mr Perfect InverPad Inverter Swimming Pool Heat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

RETURNS: Mr Perfect InverPad Inverter Swimming Pool Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

.

When a returned Mr Perfect InverPad Inverter Swimming Pool Heat Pump is received back into our warehouse our returns department confirms that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occur.

PRODUCT INFO:

Mr Perfect InverPad Inverter Swimming Pool Heat Pumps, with 5 Year On-Site Parts & Labour Labour Warranty,

are the quietest Swimming Pool Heat Pump in the UK in 2024.

In 2024 the UK's quietest heat pumps are the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps. All models have WIFI built in, and Mr Perfect Inverter Heat Pumps are 20 times quieter than other heat pumps thanks to their nearly silent fan and compressor.

For this changing world, with rising energy costs, the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps provide "All Year Round" heating by operating in temperatures as low as -15 degrees Celsius and heating water to 40 degrees Celsius whilst, at times, only using 7% of the electricity you would have used with an electric heater and 30% when compared to a standard On/Off heat pump.

With Mr Perfect InverPad Inverter Swimming Pool Heat Pumps, with 5-Year On-Site Labour Warranty and a 5 Year Parts Warranty, you can enjoy both quiet operation and all year-round heating with the knowledge you are covered in the unlikely event anything goes .

Even if you don't require year-round heating, having a swimming pool heat pump that can operate with an efficient COP at low temperatures means that the Mr Perfect InverPad Inverter Swimming Pool Heat Pumps will enable you to quickly and affordably heat an outdoor pool at the start and end of the season, which are typically the hardest times to keep the pool warm.

The Mr Perfect InverPad Inverter Swimming Pool Heat Pumps are the most up to date Swimming Pool Heating because they are loaded with the best quality components and innovative fan and evaporator design, that offers higher COP and increased effectiveness, while being even quieter than any other pool heat pump in the UK.

The Mr Perfect InverPad Inverter Swimming Pool Heat Pumps will be able to provide you with a 52 Week All-Year Round Swimming Season or just an Extended Season, depending on which size of Heat Pump you buy. So, if you require an Ultra Quiet, Super-Efficient heat pump for 12 month swimming use or only to extend the Summer season call us on 01322 554 870 to help you decide which Mr Perfect InverPad Inverter Swimming Pool Heat Pumps is best suited for your needs.

You may not require your pool heated in low temperatures but having a heat pump that will not freeze up or cut off at 10° or 5° degrees can be a huge benefit, as April and October mornings may be a lot cooler, even though you may not be using your pool you will still need to heat it to be able to use your pool in the afternoons when it is sunny and warm.

If you require help sizing your Mr Perfect InverPad Inverter Swimming Pool Heat Pumps for your pool please call us on 01322 554 870

WHAT'S INCLUDED WITH MR PERFECT SWIMMING POOL HEAT PUMP

  • 5 Year On-Site Parts & Labour Warranty
  • Dark Grey Aluminium Casing with detachable grille(s) for evaporator cleaning.
  • Built-in Wi-Fi (2.4g).
  • 2m Prewired 6mm flexible electric cable.
  • 32AMP IP61 Isolator Switch.
  • 32AMP IP67 Waterproof quick disconnect for easy cleaning and winterising.
  • 40mm Rubber Anti-Vibration Feet
  • Drainage Kit.
  • Canvas Winter Cover.
  • Kerbside Pallet Delivery.


Garden Pac Inverter Heat Pump PDF Downloads

Mr Perfect Inverpad Inverter Heat Pump With Wi-Fi Brochure



Model

Mr Perfect MPC220  22KW

Mr Perfect MPC270   27KW

Mr Perfect MPC320  32KW

Mr Perfect MPC3203   32KW  3Phase Mr Perfect MPC4203    41KW  3Phase
Operating air temperature (˚C)
-15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C -15˚C to 43˚C
Advised pool volume (m3) *
45-85 50-95 60-120 60-120 85-160
Air 27°C / Water 27°C / Humidity 80%



Heating capacity (kW) turbo mode
22.5kw 26.5kw 31.5kw 31.5kw 40.5kw
Heating capacity (kW) perfect mode 18kw 20.6kw 26.8kw 26.8kw 34.5kw
COP range 15.5~7.4 15.2~7.3 16.0~7.2 15.8~7.2 16.0~7.0
Average COP at 50% Speed 11.8 11.5 11.6 11.6 11.5
Air 15°C / Water 26°C / Humidity 70%
Heating capacity (kW) turbo mode 15.0 18.0 21.8 22.1 29.0
Heating capacity (kW) perfect mode 12.6 14.4 18.0 18.0 23.9
COP range 7.0 6.8 6.9 7.0 7.0
Power supply 230V 1Ph 230V 1Ph 230V 1Ph 400V 3Ph 400V 3Ph
Sound level at 1m dB(A) * 39.5~49.8 39.8~50.2 40.3~50.8 40.5~50.9 40.6~51.3
Sound level by 50% speed 1m dB(A) * 43.0 43.1 45.1 45.6 45.7
Sound level at 10m dB(A) * 19.5~29.8 19.8~30.2 20.3~30.8 20.5~30.9 20.6~31.3
Rated input power (kW) 0.45~3.33 0.54~4.00 0.59~4.36 0.60~4.42 0.78~5.80
Input power at 50% Speed (kW) 0.90 1.06 1.30 1.29 1.71
Rated input current (A) 1.96~14.48 2.35~17.39 2.56~18.96 0.86~6.41 1.13~8.41
Advised water flux (m3/h) 6~9 8~10 10~12 10~12 12~18
Water connection (inch) 1.5 1.5 1.5 1.5 1.5
Net dimensions LxWxH (mm)

980 x

504 x

756

1135 x

514 x

756

1029 x

512 x

1107

1029 x

512 x

1107

1139 x

512 x

1106

Net weight (kg) 91 114 136 142 160


Flotide ECO 3kw A3/32 Plug & Play Above Ground Pool Heat Pump

by World of Pools.com
Save 31%
£495.00
£340.00
  • Flotide ECO 3kw A3/32 Swimming Pool Plug & Play Heat Pump
  • Heats Your Pool Up To 30°C
  • Works When Air Temperature Is Over 12°C
  • Heat Pump For Intex, Bestway & Other Above Ground Pools
  • Suits Pools Up To 12ft x 36"
  • 2 Year Warranty

DELIVERY: Flotide ECO 3kw A3/32 Plug & Play Above Ground Pool Heat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

RETURNS: Flotide ECO 3kw A3/32 Plug & Play Above Ground Pool Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

Our returns address is Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870

When a return is received back into our warehouse our returns department confirm that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occu

PRODUCT INFO:

The Flotide 3kw A3/32 Plug & Play Heat Pump is perfect for pools up to 10m3, such as an Intex 12ft x 36" Metal Frame Pool. Only suitable for pool heating during the main Summer months. A Solar Cover must be used too. Buy Now For Same Day Despatch.

Flotide 3kw A3/32 Plug & Play Heat Pumps For Above Ground Pools are designed purely for the small above ground pool market. Intex, Bestway & Summer Escapes pools are perfect for this heat pump

The Flotide 3kw A3/32 Plug & Play Above Ground Pool Heat Pump requires 0.68kw of power to produce 3.1kw of power out. That is roughly 10p an hour to get the equivalent of 41p of heat from the Eco 3kw Heat Pump into your pool making it so much cheaper to run than an electric pool heater.  You could even recoup the outlay in the first year in savings on your electricity bill.

The minimum Flow rate from your pool pump is 2m3/hr to start the ECO 3kw Plug & Play Heat Pump For Above Ground Pools. Most Intex & Bestway pumps exceed this but check before buying

Digital Heating Control Panel - Control Heating Up To 30°C

No ByPass Required if using small Intex pumps

The Flotide 3kw A3/32 Heat Pumps are designed to heat Pool water slowly but very cost-effectively. It can raise your pool from cold to warm in 2 - 3 days, but from then on it is just a matter of keeping the heat level topped up every day. Depending on the weather you may need to run your heat pump from between 4 - 10 hours a day.

A Good Quality Solar Cover Must be Used With This Heat Pump to preserve as much heat as possible at night.

The Flotide 3kw A3/32 Plug & Play Above Ground Pool Heat Pump is suitable for pools up to 10m3

ECO Plug & Play 3kw Swimming Pool Heat Pump manual & Installation guide

Flotide Plug & Play 3kw A3/32 Heat Pump User & Installation Manual

Below are suggestions for above ground pool sizes that the ECO 3kw A3/32 Plug & Play Above Ground Pool Heat Pump is suitable for

hot splash above ground pool heat pump metal frame pool sizing

10ft x 30 inch Metal Frame Pool
12ft x 36 inch Metal Frame Pool



Intex Easy Set Heat Pump Sizing Hot Splash Heat Pump

8ft x 30 inch Easy Set Pool
10ft x 30 inch Easy Set Pool
12ft x 30 inch easy Set Pool
12ft x 36 inch Easy Set Pool



  ECO 3KW Plug & Play Heat Pump
Power Supply 220-240V 1Ph 50Hz
Heating Capacity  Air 26°C / Water 27°C 3.1KW
Heating Capacity  Air 15°C / Water 27°C 2.2KW
Input Air 26°C / Water 27°C 0.68KW
Input Air 15°C / Water 27°C 0.61KW
Current Air 26°C / Water 27°C 3.1 AMPS
Current Air 15°C / Water 27°C 2.8 AMPS
C.O.P. Air 26°C / Water 27°C 4.41
C.O.P. Air 15°C / Water 27°C 3.61
Maximum Input 0.95KW
Maximum Current 4.7 AMPS
Nominal Water Flow 2 m3/hr

Max Pool Size

(With Quality Cover)

10m3

Water Connection Size

32mm / 1.25"

Dimension (LxWxH)

mm 310 x 300 x358

Weight

24kg

Flotide A10 9.6kw Plug & Play Intex & Bestway Pool Heat Pump

by World of Pools.com
Sold out
£972.00
    • Flotide A10 9.6kw Above Ground Pool Heat Pump
    • Plugs Into A 13 amp Socket with a fitted RCD Plug
    • In Stock - 2-3 day lead time
    • Perfect Heater For Larger Intex & Bestway Pools
    • No Electrician Costs Needed To Hardwire In
    • Costs Less To Run Than A 3kw Bestway Electric Heater
    • 2 Years Parts & Labour Warranty

    DELIVERY: Flotide A10 Plug & Play Above Ground Pool Heat Pumps are sent out on a 2 working day service

    RETURNS: Flotide A10 9.6kw Plug & Play Above Ground Pool Heat Pumps can be returned unused, in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post. A Returns Number must be obtained before sending goods back.

    .

    When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors..

    PRODUCT INFO:

    Flotide A10 Plug & Play 9.6kw Above Ground Pool Heat Pumps are designed for larger Intex & Bestway pools, up to 30,000 litres. This would equate to a 20ft x 12ft Bestway pool.

    Flotide A10 Plug & Play Heat Pumps have an exceptionally high COP of 6, meaning you can get up to 6 times more heat into your pool than it will cost you in electricity.

    Flotide A10 Plug & Play Heat Pumps will function down to an air temperature of 5°C, but as with any heat pump, the warmer the air the more efficient they are and the more heat transferred into your pool. The warmer the air the better!!

    CALL US ON 01322 554 870 TO PURCHASE ANY ADDITIONAL HOSES YOU WILL NEED TO CONNECT TO YOUR POOL

    When purchasing a heat pump large enough for your pool you would usually have to take into account the cost to be hard wired into mains by and electrician on its own spurs and RCD. The Flotide A10 Plug & Play Above Ground Pool Heat Pump is reasonably priced, user friendly and runs from a standard UK 13amp 3-pin plug. Everything you could want from a heat pump unit for an above ground swimming pool.

    Below is a guide that is is based on summer use with a good solar cover being used.



    Flotide A10 Plug & Play Above Ground Pool Heat Pump pools - Pools up to 30m3

    Minimum Flow rate required 5.5m3/hr

    Supplied with 50mm sockets to connect to a bypass kit or hosetails. These can be purchased separately

    We can also assist with the correct fittings you may need to install this heater. Fittings will depend on the make and model of your pool and how far away from the pool you want the heat pump situated. Please call us on 01322554870 for help and advise on heat pump installations

    CALL US ON 01322 554 870 TO PURCHASE ANY ADDITIONAL HOSES YOU WILL NEED TO CONNECT TO YOUR POOL

    Hydro S ECO Heat Pump For Swimming Pools - World of Pools Save 15%
    • Flotide Swimming Pool Heat Pump
    • Summer Season - May to August
    • A5 HAS CONNECTIONS TO INTEX & BESTWAY 32mm & 38mm HOSE
    • Ideal Heat Pump For Summer Pools Such As Intex Or Bestway
    • Same Internal Technology As Hydropro Heat Pump
    • Frost Protection - Cuts Out Below 8°C Air Temperature
    • Same Day Dispatch & Price Match Promise



    DELIVERY: Flotide Swimming Pool Heat Pumps are sent by specialist hauliers and take between 1-3 days for delivery.

    RETURNS: Flotide Swimming Pool Heat Pumps can be returned unused and in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post. A Returns Number must be obtained before sending goods back.

    .

    When we receive the Hydro S Swimming Pool Heat Pump, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors..

    PRODUCT INFO:

    Flotide Swimming Pool Heat Pumps are the least expensive heat pumps in the UK market. Manufactured to the highest European standards, the Hydro S Heat Pump is suitable for above ground or in-ground pools. One big advantage these Heat Pumps have over other systems is the low water flow rate required, so these great Heat Pumps will even work on Intex and Bestway. 2023 models come with digital display and in a smart black casing

    Flotide Heat Pumps are manufactured in the same factory and to the same high specification as the Hydropro. The latest model now have a digital display panel and come in a smart black casing.

    The Flotide Heat Pump replaced the Hydro S Heat Pump for 2023. These new heating systems are a very cost effective way of heating your pool. As the cost of electricity has risen this type of heater has now become the most popular form of heating in the UK.

    On Mainland Europe Heat Pumps have long been used to heat Pools and the Flotide Range of Heat Pumps are manufactured by a Belgium company that have long been a market leader in the industry.

    The Flotide Heat Pumps are an extremely efficient form of heating for your water with a Coefficient Of Performance (C.O.P.) of up to 4.7, which means for every £1 it costs to run you get up to £4.70 of heat transferred to the pool. Every 1kw of electricity costs on average of 14p per hour which means that running an Elecro 7.5kw Electric Heater will cost £1.05 per hour to run. Running this heater for 8 hours per day will cost £8.40 per day to run. By running a Heat Pump you can reduce these running costs by up to 80%, which means an hourly running cost of only 18p. That equates to a saving of £5.76 per day or £170 per month. Over a 5-month period you could save £850.

    7.5kw Electric Heater Costs £216 Per Month To Run, compare this against an 8kw ECO Heat Pump that costs just £28.80 Per Month To Run

    Flotide Heat Pump Can Save You £850 Per Year

    • High Coefficient Of Performance Up To 4.8
    • Extremely Compact Unit
    • Titanium Heat Exchanger
    • Precision Temperature Control Dial
    • Low Noise Compressor & Fan
    • 2 Year Warranty

    Our Opinion

    The main advantages of a Flotide heat pump are the long term savings, these will only increase as the price of electricity increases. The capital outlay is higher than an electric heater but these should be recouped within one to two years. Other forms of heating such as electric and gas are quicker and less dependent upon the weather but in general a Flotide heat pump if correctly spec'd and installed will be the best choice for most owners.

    For help & advice on choosing the correct heat pump for your pool please call us on 01322 554 870

    Hydro S Swimming Pool Heat Pump Sizing Dimensions

    Minimum Flow Rate For Hydro S Heat Pumps

     Hydro S Heat Pump Model Minimum Flow Rate
    Flotide A5 Heat Pump 2.5 m3/h
    Flotide A7 Heat Pump 2.5 m3/h
    Flotide A10 Heat Pump 2.6 m3/h
    Flotide A13 Heat Pump 3.5 m3/h


    Flotide Swimming Pool Heat Pump - COP Curve Chart

    Flotide Swimming Pool Heat Pump - Users Manual



    The chart below is a guide to help with sizing a Hydro S Heat Pump for your above ground pool.

    Easy Set

    Above Ground Pools

    Hydro S Swimming Pool Heat Pumps For Easy Set Above Ground Pools

    Pool Size

    Cubic Metres

    Hydro S Eco Heat Pump

    8ft Diameter

    4.5

    Hydro S 3

    10ft Diameter

    5.90

    Hydro S 3

    12ft Diameter

    7.80

    Hydro S 5

    15ft Diameter

    13.40

    Hydro S 5

    18ft Diameter

    29.80

    Hydro S 7

    or

    Hydro S 10



      Metal Framed

    Above Ground Pools

    Hydro S Swimming Pool Heat Pumps For Metal Frame Above Ground Pools

    Pool Size

    Cubic Metres

    Hydro S Eco Heat Pump

    10ft Diameter

    6.70

    Hydro S 3

    12ft Diameter

    8.90

    Hydro S 5

    15ft Diameter

    17.50

    Hydro S 5

    or

    Hydro S 7

    16ft Diameter

    22.80

    Hydro S 7

    18ft Diameter

    33.40

    Hydro S 10

    21ft Diameter 48.10 Hydro S 13

    Hydropro P14 Swimming Pool Heat Pump

    by Bosta
    Sold out
    £1,475.00
    • Hydropro P14 Swimming Pool Heat Pumps
    • In Stock For Same Day Despatch
    • Sale Prices - Cheapest Online Or We Match Price
    • Suitable For All Year Use If Sized Correctly - Call For Advice
    • 2 Year Parts & Labour Warranty

    DELIVERY: Hydropro P14 Swimming Pool Heat Pumps are sent out via a specialist haulier. Delivery takes between 1-3 days.

    RETURNS: This product can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

    When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

    PRODUCT INFO:

    Hydropro P14 Heat Pump is the latest Swimming Pool Heat Pump available with R32 Gas. The hydropro heat pumps are ideal for swimming pools up to 50m3 during the main summer months, slightly less if starting in April or the beginning of May.

    As the Hydropro P14 Heat Pump will function down to -5° Celcius they can be used all year round. To function correctly it will need to be sized correctly. As a rough guide double the Ideal Size, but it is best if you call us on 01322 554 870

    Hydropro P14 Heat Pump

    Ideal Size Pool 28ft x 14ft x 4ft Deep

    Maximum Pool Size 28 ft x 14ft x 5ft Deep

    To see other sizes of hydropro heat pumps click here. Full Range Of Heat Pumps

    For help and advice call 01322 554 870



    Hydropro P14/32 Heat Pump Data



    heating power input

    2.35 kW

    heating capacity (A27/W27)

    13.5 kW

    heating capacity (A15/W26)

    9.8 kW

    maximum volume of pool

    with good insulation

    60m3 /

    60,000 litres

    coefficient (C.O.P.)  at A27/W27

    5.74

    coefficient (C.O.P.)  at A15/W25

    4.52

    compressor

    rotary

    refrigerant

    R32

    fan quantity

    1

    fan power input

    120

    fan rotate speed

    850 RPM

    fan direction

    Horizontal

    noise level (10 metres)

    43 dB (A)

    water connection

    50mm

    nominal water flow

    5.3 m/h3

    dimensions (L/W/H)

    116cm / 47cm / 87cm

    Type C or D Breaker Size 20 amp
    • Hydropro Inverter PX "All Year Round" Heat Pump
    • Energy Efficient Heater 'A' Rated R32 Gas
    • Functions down to -15° C
    • Suitable For Pools up to 150,000 litres
    • 2 Year Parts & Labour Warranty
    • Power/ Smart / Silent Modes Will Reduce Energy Costs
    • C.O.P. Up To 13 - ABS Cabinet
    • Low Noise Rotary Compressor & Fan Titanium Heat Exchanger
    • Automatic Defrost - For Colder Weather



    DELIVERY: Hydropro Inverter Swimming Pool Heat Pumps are delivered by a specialist haulier and take 1-3 days to arrive.

    RETURNS: This product can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

    .

    When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

    PRODUCT INFO:

    Hydro-Pro Inverter Heat Pumps offer massive savings during the Sumer months when compared to other heat pumps. With C.O.P.s of up to 13 the Hydropro Inverter Heat Pumps are not only quiet but are one of the most advanced in technology. Using R32 Gas they are not only better for the environment than older style heat pumps but dramatically more effective too.

    If you are looking to buy a heat pump for the future as well as for now the Hydropro Z Inverter range is suited to you.

    With each £1 of power input you can have an output of up to £13 when in Silent Mode.

    Having three settings the Hydropro Inverter Heat Pump can offer Super Quiet running whilst in the Silent Mode, ideal if running overnight or during the main Summer months. The Smart Mode uses al three modes to maintain your pool at a set temperature and the Powerful Mode is ideal when opening your pool or after inclement weather.

    Hydro-Pro Inverter Type heat pumps are very quiet running as the use a variable speed motor along with a low noise DC Inverter rotary compressor and fan.

    Anti-Vibration Rubber Pads which fit under the four feet on the unit will help even further to reduce noise.

     Heat Pump Model

    Maximum Pool Size

    Hydropro Inverter PX7/32

    30,000 Liters

    Hydropro Inverter PX11/32 45,000 Litres
    Hydropro Inverter PX14/32 60,000 Litres

    Hydropro Inverter PX17/32

    75,000 Litres

    Hydropro Inverter PX21/32

    90,000 Litres

    Hydropro Inverter PX25/32

    Hydropro Interter PX30/32

    120,000 Litres

    150,000 Litres



    All Hydropro PX Type Inverter Heat Pumps are fitted with an automatic defrost and the ability to work down to -5 C, giving you 12 month, all year round heating of your indoor pool. With three settings, 'Power', 'Smart' & 'Silent' allowing you to adjust the output to suit weather conditions, saving you up to 30% in running costs, you will find the Hydropro PX Inverter Heat Pumps will suit your needs perfectly.



    If you are planning to use your Hydropro PX Type Inverter Heat Pump for Summer or Extended Season only, then using the guide above will help. But if you want to size your Hydro-Pro Inverter heat pump correctly for All Year Round use, please call us on 01322 554 870 as there are a number of factors we need to be taken into account before we can correctly advise which model you will need. These will include pool size, hours used per day, preferred water temperature and whether the pool is insulated.

    Sizing an all year round swimming pool heat pump uses different parameters than a standard model, so calling us on 01322 554 870 before ordering is essential.

    • Garden Pac Invertech Swimming Pool Heat Pump With Wi-Fi
    • Quietest Swimming Pool Heat Pump In The UK
    • 2023 Models 10 Times Quieter Than Most Heat Pumps
    • Inverter Heat Pump Technology - Complete Variable Speed - Not Stepped
    • COP up to 15 - Operates Down To -7° C - R32 Gas With Soft Start
    • 7 Year Titanium Heat Exchanger & Mitsubishi Compressor Warranty
    • 2 Years Parts Warranty

    DELIVERY: Garden Pac Invertech InverterHeat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

    RETURNS: Garden Pac Invertech Inverter Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

    .

    When a returned Garden Pac Inverter Heat Pump is received back into our warehouse our returns department confirms that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occur.

    PRODUCT INFO:

    Garden Pac Invertech Heat Pumps are the quietest Swimming Pool Heat Pump in the UK.  Buy now for a Next Working Day delivery.

    The new 2021 model Garden Pac Invertech Heat Pumps takes inverter heat pump technology to the next level. Making them Super Quiet and Super Efficient. Each Heat Pump also comes with a Wi-Fi connection, controlled using a Smart Phone App.

    Each Garden Pac Heat Pump has a Twin-Rotary Mitsubishi DC Inverter Compressor. This innovative technology is based on the "Twin Mechanism" solution where two rotors work in sync to reduce the shaking, found in all heat pumps caused by the compressor, by balancing the tork, along with a DC brushless fan motor, with low noise and very low power usage. This has the benefits of not only an exceptionally quiet operation but also extremely high efficiency.

    As in the previous incarnation of the Garden Pac Invertech Heat Pump the unit will operate down to -7 degrees, although heat output will obviously be restricted at this temperature. During the main Summer months with an air temperature of  26° C, the Garden Pac can offer a COP of up to 15.

    The Garden Pac Invertech heat pump will be able to offer you a 12 Month  Swimming Season or just an Extended Season swimming pool heating system. It is all dependant on the sizing of the Heat Pump. So, if you require an Ultra Quiet, Super-Efficient heat pump for all year round use or only to extend the Summer season call us to help you decide which Garden Pac Invertech is best suited for your needs.

    As a Swimming Pool Heat Pump should be a long term investment it is important to not only look at the price but also the quality. Although the Garden Pac Inverter Heat Pump is dearer than standard heat pumps it is cheaper than its comparable Inverter models with the same technology. Some Inverter heat pumps are "stepped" variable speeds, but the Garden Pac is a complete variable speed, offering the quietest and most efficient performance. You will want your Heat Pump to last a long time, so it makes sense to buy one that is at the forefront of technology when you do.

    The Garden Pac Invertech Inverter Heat Pump functions in temperatures as low as -7° Celsius, but as with all heat pumps they operate most efficiently when the air temperature is above 15° Celsius, providing a cop of up to 15 when the air temperature is at a balmy 26° Celsius. It is important to remember that the Garden Pac will draw the warm ambient air temperature from the reverse of the unit and blow the cold waste air horizontally from its fan. This means the Heat Pump requires a reasonable amount of space around it.  We would recommend a minimum of 500mm around the back, 750mm sides and at least 3 metres to the front. The Garden Pac should not be enclosed in a shed or other structure restricting air-flow to and away from the unit.

    The Inverter Garden Pac Heat Pumps come with a Green ABS cabinet, not only to protect it all year round from the UK weather conditions but also to blend into the garden area, the free of charge winter cover also comes in green so the Garden Pac will be hidden all year round.

    You may not require your pool heated in low temperatures but having a heat pump that will not freeze up or cut off at 10° or 5° degrees can be a huge benefit, as April and October mornings may be a lot cooler, even though you may not be using your pool you will still need to heat it to be able to use your pool in the afternoons when it is sunny and warm.

    If you require help sizing your heat pump for your pool please call us on 01322 554 870

    Garden Pac Inverter Heat Pump PDF Downloads

    Garden Pac Invertech Heat Pump With Wi-Fi Brochure

    Garden Pac Invertech Heat Pump With Wi-Fi Installation Manual

    Model

    Power Output  At Air 26° C

    Max Pool Size (m3)

     Power Input & Output At Air 15°C

    GHD-150-0251

    10.3kw

    25-45 m3

    0.19kw – 1.5kw

    7.1kw

    GHD-150-0252

    12.8kw

    35-65 m3

    0.27kw – 2.2kw

    8.3kw

    GHD-150-0254

    17.3kw

    40-75 m3

    0.33kw – 2.6kw

    11.5kw

    GHD-150-0255

    20.3kw

    50-95 m3

    0.38kw – 3.3kw

    14kw

    GHD-150-0256

    27.3kw

    65-120 m3

    0.57kw – 3.8kw

    18kw

    (3-Phase) -

    GHD-150-0258

    27kw

    65-120 m3

    0.53kw – 3.9kw

    18kw



    • Hydropro P8/32 Swimming Pool Heat Pump
    • Suitable For All Year Use If Sized Correctly - Call For Advice
    • Hydropro P8 - Maximum 30m3 Pool - Summer Use
    • 2 Years Parts & Labour Warranty
    • 7 Years Compressor & Heat Exchanger Warranty
    • We Price Match & Ship Same Day

    DELIVERY: Hydropro P8/32 Swimming Pool Heat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

    RETURNS: Hydropro P8/32 Swimming Pool Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

    .

    When a return is received back into our warehouse our returns department confirm that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occur.

    PRODUCT INFO:

    Hydropro P8/32 Heat Pump is ideally sized for a 15ft x 48" Above Ground Pool to extend the Swimming season from May to September. A good Solar Cover must be used in conjunction with the heater

    Hydro Pro P8 Heat Pump

    Ideal Pool Size 15ft x 48" Round

    Maximum Pool Size 20ft x 12ft x 4ft Oval

    Hydropro P8 Swimming Pool Heat Pumps are capable of both heating and cooling and will perfectly suit small pools with a maximum volume of water of 30m3 if used during the main summer months. Outside of the main Summer months, the heat pump should be used on smaller pools. Realistically, the Hydropro P8 could heat a pool with a capacity of 15m3 All Year Round, if insulated properly.

    Using the Hydropro P8/32 to heat your pool for an extended season of May to September we would suggest that your pool is a maximum size of 15ft round x 48" deep.

    The HydroPro P range of heat pumps has a working ambient air temperature of  –5 degrees Celcius, although at this temperature reduced C.O.P. and output is reduced. It might not seem that you need to heat your pool in low temperatures but having a Swimming Pool Heat Pump that will not cut out when the air temperature reaches 8 or 10 degrees Celcius has huge benefits at the beginning and end of the Extended Swimming Season. At these times of the year the morning and evening air temperatures can be as low as 5 degrees Celcius. When other heat pumps will stop working the Hydropro P8/32 will still be heating your pool for you to use whenever you want to.

    Outside installation is required for the Hydropro P8 to function correctly. Reduced airflow, both in or out, will dramatically reduce performance

    With over 15 Years experience sizing and supplying Swimming Pool Heat Pumps we can provide Expert advice and save you a massive 80% on your heating bills. The Hydropro P8/32 Swimming Pool Heat Pump is despatched on the Same Day as ordering.

    For help and advice on sizing your heat pump correctly call 01322 554 870

    Hydropro P8/32 Swimming Pool Heat Pump - Users Manual English

    Hydropro P8/32 Swimming Pool Heat Pump - COP Curve



     Hydropro P Series Heat Pump Diagram

    Hydropro P8/32 Heat Pump Data



    heating power input

    1.32 kW

    heating capacity (A27/W27)

    8.31 kW

    heating capacity (A15/W26)

    5.71 kW

    maximum volume of pool

    with good insulation

    30m3

    30,000 Litres

    running current

    5.9 AMPS

    coefficient (C.O.P.)  at A27/W27

    6.34

    coefficient (C.O.P.)  at A15/W25

    4.33

    compressor

    rotary

    refrigerant

    R32

    fan quantity

    1

    fan power input

    80

    fan rotate speed

    850 RPM

    fan direction

    Horizontal

    noise level (10 metres)

    42 dB (A)

    water connection

    50mm

    nominal water flow

    3 m/h3

    dimensions (L/W/H)

    95cm / 35cm / 60cm

    unit shipping dimensions (L/W/H)

    97cm  / 37cm / 62cm

    net weight/ shipping weight

    47 KG

    slow fuse current

    15  AMPS
