DELIVERY: We aim to send Poolstyle Inverter Heat Pumps out on a next working day service but all standard deliveries will be within 5 working days
RETURNS:
Poolstyle Inverter Swimming Pool Heat Pumps can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.
When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.
PRODUCT INFO:
Manufactured for PoolCorp, a Worldwide pool company with around £3Billion per year turnover, they are made to the highest specification and backed by the largest pool company in the World.
The 2024 Poolstyle Inverter has built in WiFi, allowing Real-Time monitoring and simple control of the heat pump, where ever you are.
Poolstyle Inverter Swimming Pool Heat Pump 9kw & 11kw Features :
If you would like help choosing which Poolstyle Step Inverter Heat Pump is most suitable for your swimming pool please call us on 01322 554 870. We will be more than happy to help.
Model | 9kW | 11.5kW | 18.5kW |
Performance condition: Ambient temperature (DB/WB) 27c/24.3c, Water Inlet/Outlet Temperature 26c/28c | |||
Heating Capacity kW | 1.8-9.5 | 3.5-15.3 | 4.78-25.3 |
Consumed Power kW | 0.124-1.46 | 0.243-2.41 | 0.34-4.3 |
COP w/w | 14.5-6.5 | 14.4-6.35 | 14.1-5.88 |
Boost Mode Heating Capacity kW/COP | 9.5kW 6.5 COP | 15.3kW 6.35 COP | 25.3kW 5.88 COP |
Smart Mode Heating Capacity kW/COP | 7.8kW 7.52 COP | 11.55kW 7.68 COP | 20.4kW 7.6 COP |
Silent Mode Heating Capacity kW/COP | 3.5kW 12.2 COP | 7.35kW 10.62 COP | 12.3kW 10.2 COP |
Performance condition: Ambient temperature (DB/WB) 15c/12c, Water Inlet/Outlet Temperature 26c/28c | |||
Heating Capacity kW | 1.5-7.9 | 2.95-11.15 | 3.8-17.1 |
Consumed Power kW | 0.194-1.491 | 0.386-2.226 | 0.49-3.47 |
COP w/w | 7.73-5.3 | 7.64-5.01 | 7.76-4.93 |
Boost Mode Heating Capacity kW/COP | 7.9kW 5.3 COP | 11.5kW 5.01 COP | 17.1kW 4.93 COP |
Smart Mode Heating Capacity kW/COP | 6.1kW 5.95 COP | 8.65kW 5.72 COP | 11.5kW 5.84 COP |
Silent Mode Heating Capacity kW/COP | 2.5kW 6.92 COP | 5.55kW 6.55 COP | 8.3kW 6.52 COP |
Operating Air Temperature | -10c to 43c | ||
Heating Temperature range | 9c to 40c | ||
Cooling Temperature range | 8c to 35c | ||
Recommended pool volume | 20-40m3 | 30-60m3 | 55-90m3 |
Max Power output | 1.75kW | 3.2kW | 4.5kW |
Max current | 7.95A | 14.5A | 19.5A |
Air volume m3/h | 900 | 1300 | 1600 |
Sound Pressure | 33-46dB | 34-48dB | 35-55dB |
Water Flow volume | 4.1m3/h | 6.6m3/h | 10.8m3/h |
Water pipe connection | 50mm |
DELIVERY: Hydropro P12 Swimming Pool Heat Pumps are sent out via a specialist haulier. Delivery takes between 1-3 days.
RETURNS: This product can be returned in original packaging, suitable for resale, within 14 days from date of delivery. When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.
PRODUCT INFO:
Comes complete with Plug and Play Cable Kit that needs to be installed by a competent person so perfect for inground and above ground pools
As the Hydropro P14 Heat Pump will function even when the ambient air temperature is as low as 0° Celcius they can be used all year round, but with reduced C.O.P. and output. To function correctly the heat pump will need to be sized correctly. As a very rough guide, it is suggested to at least double the Ideal Size, but it is advisable if you call us on 01322 554 870 to ensure suitability.
Hydropro P12 Heat Pump - Summer Use
Ideal Size Pool 24ft x 12ft x 4ft Deep
Maximum Pool Size 24 ft x 12ft x 5ft Deep
To see other sizes of hydropro heat pumps click here. Full Range Of Heat Pumps
For help and advice call 01322 554 870
Hydropro P12/32 Heat Pump Data
|
|
heating power input |
1.95 kW |
heating capacity (A27/W27) |
11.5 kW |
heating capacity (A15/W26) |
6.5 kW |
maximum volume of pool with good insulation |
50m3 / 50,000 litres |
coefficient (C.O.P.) at A27/W27 |
5.90 |
coefficient (C.O.P.) at A15/W25 |
4.59 |
compressor |
rotary |
refrigerant |
R32 |
fan quantity |
1 |
fan power input |
90 |
fan rotate speed |
850 RPM |
fan direction |
Horizontal |
noise level (10 metres) |
43 dB (A) |
water connection |
50mm |
nominal water flow |
4.5 m/h3 |
dimensions (L/W/H) |
100cm / 39cm / 60cm |
Type C or D Breaker Size | 15 amp |
DELIVERY: We aim to send all products out on a next working day service but all standard deliveries will be within 5 working days
RETURNS: The Hydropro P20 Heat Pump can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.
When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.
PRODUCT INFO:
Hydro Pro P20 Heat Pump
Ideal Size Pool - 30ft x 15ft x 4ft Deep
Maximum Size Pool - 30ft x 15ft x 5ft Deep
The Hydropro P20 will produce roughly 20kw of energy at 27 degrees air temp and nearly 14kw at 15 degrees while only drawing 2.87kw, making it an effective cost saving heating solution for your swimming pool. The Hydropro P20 contains the latest R32 gas making it more enviromentally freindly and better performing.These heat pumps need to have good ventilation and shuould be postition in an outdoor free to allow the ambient air to be drawn in and free to allow the cold air to escape
As an example the ideal size pool for this hydropro P20 swimming pool heat pump is a 30ft x 15ft that is 4ft deep swimming pool, although this is just a basic guide.
For help and advice call 01322 554 870
Hydropro P20 Heat Pump Data |
|
Power Input |
2.87 kW |
Heating Capacity (A27/W27) |
19.5 kW |
Heating Capacity (A15/W26) |
13.8 kW |
Maximum Volume of Pool With Good Insulation |
70m3 / 70,000 litres |
Running Current |
12.8 Amps |
Power Supply Type C or D breaker |
35 AMPS |
Coefficient (C.O.P.) at A27/W27 |
6.3 |
Coefficient (C.O.P.) at A15/W25 |
4.81 |
Compressor |
Rotary |
Refrigerant |
R32 |
Fan Quantity |
1 |
Fan Power Input |
2000 |
Fan Rotate Speed |
850 RPM |
Fan Direction |
Horizontal |
Noise Level (10 metres) |
57 dB (A) |
Water Connection |
50mm |
Minimum Water Flow |
6.8 m3/h |
Dimensions (L/W/H) |
115cm / 47cm / 87cm |
DELIVERY: We aim to send all products out on a next working day service but all standard deliveries will be within 5 working days
RETURNS: The Hydropro P20 Heat Pump can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.
Returns Address: Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870
When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.
PRODUCT INFO:
Hydro Pro P20 Heat Pump
Ideal Size Pool - 30ft x 15ft x 4ft Deep
Maximum Size Pool - 30ft x 15ft x 5ft Deep
The Hydropro P20 will produce roughly 20kw of energy at 27 degrees air temp and nearly 14kw at 15 degrees while only drawing 2.87kw, making it an effective cost saving heating solution for your swimming pool. The Hydropro P20 contains the latest R32 gas making it more enviromentally freindly and better performing.These heat pumps need to have good ventilation and shuould be postition in an outdoor free to allow the ambient air to be drawn in and free to allow the cold air to escape
As an example the ideal size pool for this hydropro P20 swimming pool heat pump is a 30ft x 15ft that is 4ft deep swimming pool, although this is just a basic guide.
For help and advice call 01322 554 870
Hydropro P20 Heat Pump Data |
|
Power Input |
2.87 kW |
Heating Capacity (A27/W27) |
19.5 kW |
Heating Capacity (A15/W26) |
13.8 kW |
Maximum Volume of Pool With Good Insulation |
70m3 / 70,000 litres |
Running Current |
12.8 Amps |
Power Supply Type C or D breaker |
35 AMPS |
Coefficient (C.O.P.) at A27/W27 |
6.3 |
Coefficient (C.O.P.) at A15/W25 |
4.81 |
Compressor |
Rotary |
Refrigerant |
R32 |
Fan Quantity |
1 |
Fan Power Input |
2000 |
Fan Rotate Speed |
850 RPM |
Fan Direction |
Horizontal |
Noise Level (10 metres) |
57 dB (A) |
Water Connection |
50mm |
Minimum Water Flow |
6.8 m3/h |
Dimensions (L/W/H) |
115cm / 47cm / 87cm |
