Inverter Pool Heat Pumps

  • Hydropro Inverter "All Year Round" Heat Pump
  • Latest Px range replaces old Z range
  • Energy Efficient Heater 'A' Rated R32 Gas
  • Functions down to -15° C
  • Suitable For Pools up to 150,000 litres
  • 2 Year Parts & Labour Warranty
  • Power/ Smart / Silent Modes Will Reduce Energy Costs
  • C.O.P. Up To 13
  • ABS Cabinet
  • Low Noise Rotary Compressor & Fan Titanium Heat Exchanger
  • Automatic Defrost - For Colder Weather



DELIVERY: Hydropro Inverter Swimming Pool Heat Pumps are delivered by a specialist haulier and take 1-3 days to arrive.

RETURNS: This product can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

Returns Address: Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870

When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

PRODUCT INFO:

Hydro-Pro Inverter Heat Pumps offer massive savings during the Sumer months when compared to other heat pumps. With C.O.P.s of up to 13 the Hydropro Inverter Heat Pumps are not only quiet but are one of the most advanced in technology. Using R32 Gas they are not only better for the environment than older style heat pumps but dramatically more effective too.

If you are looking to buy a heat pump for the future as well as for now the Hydropro Z Inverter range is suited to you.

With each £1 of power input you can have an output of up to £13 when in Silent Mode.

Having three settings the Hydropro Inverter Heat Pump can offer Super Quiet running whilst in the Silent Mode, ideal if running overnight or during the main Summer months. The Smart Mode uses al three modes to maintain your pool at a set temperature and the Powerful Mode is ideal when opening your pool or after inclement weather.

Hydro-Pro Inverter Type heat pumps are very quiet running as the use a variable speed motor along with a low noise DC Inverter rotary compressor and fan.

Anti-Vibration Rubber Pads which fit under the four feet on the unit will help even further to reduce noise.

 Heat Pump Model

Maximum Pool Size

Hydropro Inverter Px7/32

30,000 Liters

Hydropro Inverter PX11/32 45,000 Litres
Hydropro Inverter PX14/32 60,000 Litres

Hydropro Inverter PX17/32

75,000 Litres

Hydropro Inverter PX21/32

90,000 Litres

Hydropro Inverter PX25/32

Hydropro Interter PX30/32

120,000 Litres

150,000 Litres



All Hydropro X Type Inverter Heat Pumps are fitted with an automatic defrost and the ability to work down to -5 C, giving you 12 month, all year round heating of your indoor pool. With three settings, 'Power', 'Smart' & 'Silent' allowing you to adjust the output to suit weather conditions, saving you up to 30% in running costs, you will find the Hydropro Inverter Heat Pumps will suit your needs perfectly.



If you are planning to use your Hydropro X Type Inverter Heat Pump for Summer or Extended Season only, then using the guide above will help. But if you want to size your Hydro-Pro Inverter heat pump correctly for All Year Round use, please call us on 01322 554 870 as there are a number of factors we need to be taken into account before we can correctly advise which model you will need. These will include pool size, hours used per day, preferred water temperature and whether the pool is insulated.

Sizing an all year round swimming pool heat pump uses different parameters than a standard model, so calling us on 01322 554 870 before ordering is essential.

  • Garden Pac Invertech Swimming Pool Heat Pump With Wi-Fi
  • Quietest Swimming Pool Heat Pump In The UK
  • 2021 Models 10 Times Quieter Than Most Heat Pumps
  • Inverter Heat Pump Technology - Complete Variable Speed - Not Stepped
  • COP up to 15 - Operates Down To -7° C - R32 Gas With Soft Start
  • 7 Year Titanium Heat Exchanger & Mitsubishi Compressor Warranty
  • 2 Years Parts Warranty

DELIVERY: Garden Pac Invertech InverterHeat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

RETURNS: Garden Pac Invertech Inverter Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

Our returns address is Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870

When a returned Garden Pac Inverter Heat Pump is received back into our warehouse our returns department confirms that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occur.

PRODUCT INFO:

Garden Pac Invertech Heat Pumps are the quietest Swimming Pool Heat Pump in the UK.  Buy now for a Next Working Day delivery.

The new 2021 model Garden Pac Invertech Heat Pumps takes inverter heat pump technology to the next level. Making them Super Quiet and Super Efficient. Each Heat Pump also comes with a Wi-Fi connection, controlled using a Smart Phone App.

Each Garden Pac Heat Pump has a Twin-Rotary Mitsubishi DC Inverter Compressor. This innovative technology is based on the "Twin Mechanism" solution where two rotors work in sync to reduce the shaking, found in all heat pumps caused by the compressor, by balancing the tork, along with a DC brushless fan motor, with low noise and very low power usage. This has the benefits of not only an exceptionally quiet operation but also extremely high efficiency.

As in the previous incarnation of the Garden Pac Invertech Heat Pump the unit will operate down to -7 degrees, although heat output will obviously be restricted at this temperature. During the main Summer months with an air temperature of  26° C, the Garden Pac can offer a COP of up to 15.

The Garden Pac Invertech heat pump will be able to offer you a 12 Month  Swimming Season or just an Extended Season swimming pool heating system. It is all dependant on the sizing of the Heat Pump. So, if you require an Ultra Quiet, Super-Efficient heat pump for all year round use or only to extend the Summer season call us to help you decide which Garden Pac Invertech is best suited for your needs.

As a Swimming Pool Heat Pump should be a long term investment it is important to not only look at the price but also the quality. Although the Garden Pac Inverter Heat Pump is dearer than standard heat pumps it is cheaper than its comparable Inverter models with the same technology. Some Inverter heat pumps are "stepped" variable speeds, but the Garden Pac is a complete variable speed, offering the quietest and most efficient performance. You will want your Heat Pump to last a long time, so it makes sense to buy one that is at the forefront of technology when you do.

The Garden Pac Invertech Inverter Heat Pump functions in temperatures as low as -7° Celsius, but as with all heat pumps they operate most efficiently when the air temperature is above 15° Celsius, providing a cop of up to 15 when the air temperature is at a balmy 26° Celsius. It is important to remember that the Garden Pac will draw the warm ambient air temperature from the reverse of the unit and blow the cold waste air horizontally from its fan. This means the Heat Pump requires a reasonable amount of space around it.  We would recommend a minimum of 500mm around the back, 750mm sides and at least 3 metres to the front. The Garden Pac should not be enclosed in a shed or other structure restricting air-flow to and away from the unit.

The Inverter Garden Pac Heat Pumps come with a Green ABS cabinet, not only to protect it all year round from the UK weather conditions but also to blend into the garden area, the free of charge winter cover also comes in green so the Garden Pac will be hidden all year round.

You may not require your pool heated in low temperatures but having a heat pump that will not freeze up or cut off at 10° or 5° degrees can be a huge benefit, as April and October mornings may be a lot cooler, even though you may not be using your pool you will still need to heat it to be able to use your pool in the afternoons when it is sunny and warm.

If you require help sizing your heat pump for your pool please call us on 01322 554 870

Garden Pac Inverter Heat Pump PDF Downloads

Garden Pac Invertech Heat Pump With Wi-Fi Brochure

Garden Pac Invertech Heat Pump With Wi-Fi Installation Manual

Model

Power Output  At Air 26° C

Max Pool Size (m3)

 Power Input & Output At Air 15°C

GHD-150-0251

10.3kw

25-45 m3

0.19kw – 1.5kw

7.1kw

GHD-150-0252

12.8kw

35-65 m3

0.27kw – 2.2kw

8.3kw

GHD-150-0254

17.3kw

40-75 m3

0.33kw – 2.6kw

11.5kw

GHD-150-0255

20.3kw

50-95 m3

0.38kw – 3.3kw

14kw

GHD-150-0256

27.3kw

65-120 m3

0.57kw – 3.8kw

18kw

(3-Phase) -

GHD-150-0258

27kw

65-120 m3

0.53kw – 3.9kw

18kw

  • InverSmart 9kw Inverter + Wi-Fi Swimming Pool Heat Pump
  • Mitsubishi Full Stepless Inverter Compressor
  • Reduce Electricity Bills By 80%
  • Patented Unique Front Air-Stream Fanless Design
  • Wi-Fi App Controlled
  • Ideal For March To October Swimming Season
  • All Year Round Pool Heating Option - Call For Advice
  • Price Match & Stock For Same Day Despatch

DELIVERY: Inversmart 9kw Inverter Swimming Pool Heat Pumps + Wi-Fi are delivered by a specialist haulier and take 1-3 days to arrive.

RETURNS: 9kw Inversmart Inverter swimming pool heat pumps can be returned unused and in the original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

Returns Address: Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870

When we receive the Inversmart 9kw Inverter Heat Pump, our returns department confirm that everything is present and in its original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

PRODUCT INFO:

InverSmart 9kw Inverter Swimming Pool Heat Pumps are Full Inverter Heat Pumps, unlike other Stepped Inverter heat pumps available in the UK. The Inversmart will give you smaller electricity bills and quieter running. The return on investment, when compared with other heat pumps, can be as little as one swimming season. After that, you are just saving money every year.

The InverSmart 9kw Inverter Swimming Pool Heat Pump uses the most up-to-date Stepless DC Full Inverter technology in its top-of-the-range Mitsubishi Compressor as well as a Brushless DC Fan Motor providing huge energy savings when compared with other heat pumps.

When TheHeat Your Pool From Only 10p Per Hour With An InverSmart 9kw Stepless Inverter Heat Pump

inverter smart inverter swimming pool heat pump

The 9kw InverSmart Swimming Pool Heat Pump running costs can be less than 12p per hour to heat a 20ft x 10ft swimming pool, making the InverSmart Heat Pump the cheapest way to heat a swimming pool.

Environmentally Friendly Swimming Pool Heating

The 9kw InverSmart Swimming Pool Heat Pump uses the more environmentally friendly R32 Refrigerant gas rather than the older R410A gas used by other heat pumps. It costs more to produce than the cheaper R410A gas, but R32 gas means the 9kw InverSmart Inverter Swimming Pool Heat Pump can achieve its amazing output.

InverSmart Inverter Swimming Pool Heat Pump Features & Improvements

  • High C.O.P. of 13
  • Stepless Full DC Inverter
  • As Quiet As A Fridge
  • As Litle As 10p Per Hour To Run
  • Wi-Fi App Controlled
  • Mitsubishi Compressor
  • Twisted Titanium Heat Exchanger
  • Patented Air-Stream Design
  • Anti Rust ABS & Aluminium Alloy Casing
  • R32 Gas
  • Electronic Expansion Valve
  • Hot Gas Defrost

Cheaper & Quieter Swimming Pool Heating With An Inversmart Heat Pump

One of the advantages that the Inversmart 9kw Swimming Pool Inverter Heat Pump has over its competition is the extremely low running costs and the ultra-quiet operation, as quiet as a fridge in the ultra-efficient mode. This is because it has a Full, Stepless Inverter. There are three types of Swimming Pool Heat Pump, an On/Off model, a "Stepped Inverter"and the "Full Stepless Inverter" on the InverSmart Swimming Pool Heat Pump will change between all of these settings seamlessly always providing the maximum heat output at the lowest possible cost.

Highest Quality Components In A Heat Pump For Pools

The Inversmart Inverter Swimming Pool Heat Pump has a Mitsubishi Compressor, a Twisted Titanium Heat Exchanger and an ultra-effective Patented Air Stream Design, drawing air from the side and exhausting via the rear.

The Inversmart Inverter Swimming Pool Heat Pump Is Supplied With Winter Cover & Condensation Ducting Tubes

How To Choose The Right Size Heat Pump For Your Swimming Pool

We provide suggestions for pool sizes given by the manufacturer, but the size of your heat pump will depend on location in the UK, position that the heat pump is sited, desired water temperature, the number of hours bathing and the type of swimming pool you have, whether above ground or inground and if it is insulated. This can be a very difficult choice if you are not sure of the limitations of a heat pump, but we have over 15 Years of experience, with many thousands of happy customers running our heat pumps on their pools, so we are extremely proficient in helping you choose the ideal heat pump for your swimming poo

  InverSmart 9kw Heat Pump

PERFORMANCE CONDITION:

Air 27°C/ Water 27°C/ Humidity 80%

Heating Capaity (KW) 9kw
C.O.P. Range On Inverter 14.0 ~ 6.5
Average C.O.P. At 50% Speed 9

PERFORMANCE CONDITION:

Air 15°C/ Water 26°C/ Humidity 70%

Heating Capacity (KW) 6.5kw
COP Range 6.8 ~ 4.5
Average COP At 50% Speed 6.2
TECHNICAL SPECIFICATIONS
Suggested Pool Volume 20m3 - 50m3
Operating Air Temperature Air -5°C ~ 40°C
Compressor Twin-Rotary Mitsubishi DC Compressor
Casing ABS & Aluminium Alloy
Heat Exchanger Twisted Titanium Heat Exchanger
Power Supply 230V ~ 1Ph
Rated Input Power 0.24kw ~ 1.45kw
Input Power At 50% Speed 0.53kw
Rated Input Current 1.05A ~ 6.4A
Sound Level At 10m dB(A) 19 dB(A) ~ 28.4 dB(A)
Sound Level At 1m dB(A) 39 dB(A) ~ 48.4 dB(A)
Sound Level 50% Speed At 1m 41.6 dB(A)
Advised Water Flow Rate 2m3 ~ 4m3
Water Connection 50mm / 1.5"
Dimension (L x W x H) 890mmx 440mm x 658mm
Weight  52kg
If you would like help or advice sizing your heat pump for your pool please call us on 01322 554 870



  • Garden Pac Vertical Invertech Turbo Swimming Pool Heat Pump With Wi-Fi
  • "Turbo Boost" Option Gives 120% Output For Urgent Heating
  • 2021 Models 6 Times Quieter Than Most Heat Pumps
  • Inverter Heat Pump Technology - Complete Variable Speed - COP up to 15
  • Operates Down To -7°C - Heats Water Up To 40°C - R32 Gas With Soft Start
  • Heats & Cools Water - Suitable For Holiday Homes - WiFi Controllable
  • 7 Year Titanium Heat Exchanger & Mitsubishi Compressor Warranty
  • 2 Years Parts Warranty

DELIVERY: Garden Pac Vertical Invertech Turbo Inverter Heat Pumps are sent out via a specialist carrier. Delivery will normally take between 1-3 days, but please allow 5 working days in some extreme cases.

RETURNS: Garden Pac Vertical Invertech Turbo Inverter Heat Pumps can be returned to us, in compliance with the Consumer Contracts Regulations, unused and in their original packaging, suitable for resale, within 14 days from date of delivery. Returns should always be sent via "Signed For" carrier or postal service.

Our returns address is Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870

When a returned Garden Pac Vertical Invertech Turbo Inverter Heat Pump is received back into our warehouse our returns department confirms that everything is present and that the item is in its original condition, to make sure it is eligible for a refund. We will process the refund normally on the same day we take them in, but please allow up to a maximum of 14 working days for the money to reach your bank or credit card. It is unlikely to take this long but due to reasons such as bank delays or errors, this may occasionally occur.

PRODUCT INFO:

Garden Pac Vertical Invertech Turbo Heat Pumps are designed for modern-day Swimming Pool Heating. Capable of both Heating & Cooling the swimming pool water they are ideal for Holiday Homes & Holiday Lets. Controllable by WiFi, allowing full access wherever you are in the world. Buy now for a Next Working Day delivery.

The new 2021 model Garden Pac Vertical Invertech Turbo Heat Pumps takes inverter heat pump technology to the next level, having a Turbo option for when speedy heating is required. The Vertical Waste Fan allows for siting near the pool without cold air being blown onto bathers, or sunbathers alike. Each Heat Pump also comes with a Wi-Fi connection, controlled using a Smart Phone App.

Each Garden Pac Heat Pump has a Twin-Rotary Mitsubishi DC Inverter Compressor. This innovative technology is based on the "Twin Mechanism" solution where two rotors work in sync to reduce the shaking, found in all heat pumps caused by the compressor, by balancing the torque, along with a DC brushless fan motor, with low noise and very low power usage. This has the benefits of not only an exceptionally quiet operation but also extremely high efficiency.

The Garden Pac Vertical Invertech Turbo Heat Pump the unit will operate down to -7 degrees, although heat output will obviously be restricted at this temperature. During the main Summer months with an air temperature of  26° C, the Garden Pac can offer a COP of up to 15 and has the capability of heating pool or spa water up to 40°C.

The Garden Pac Vertical Invertech Turbo heat pump will be able to offer you a 12 Month  Swimming Season or just an Extended Season swimming pool heating system. It is all dependant on the sizing of the Heat Pump. So, if you require an Ultra Quiet, Super-Efficient heat pump for all year round use or only to extend the Summer season call us to help you decide which Garden Pac Invertech is best suited for your needs.

As your Swimming Pool Heat Pump should be a long term investment it is important to not only look at the price but also the quality. Although the Garden Pac Vertical Invertertech Turbo Heat Pump is dearer than standard heat pumps it has technology and component quality, Mitsubishi compressor for example, that other heat pumps do not have. You will want your Heat Pump to last a long time and work when you need it to, so it makes sense to buy one that is at the forefront of technology when you do.

The Garden Pac Vertical InvertechTurbo Inverter Heat Pump functions in temperatures as low as -7° Celsius, but as with all heat pumps they operate most efficiently when the air temperature is above 15° Celsius, providing a cop of up to 15 when the air temperature is at a balmy 26° Celsius. It is important to remember that the Garden Pac will draw the warm ambient air temperature from the sides of the unit and blow the cold waste air vertically from its fan. This means the Heat Pump requires less space around it than side-mounted fan models.  We would recommend a minimum of 300mm clearance all round and at least 3 metres above it. The Garden Pac Vertical Turbo should not be enclosed in a shed or other structure restricting air-flow to and away from the unit.

You may not require your pool heated in low temperatures but having a heat pump that will not freeze up or cut off at 10° or 5° degrees can be a huge benefit, as April and October mornings may be a lot cooler, even though you may not be using your pool you will still need to heat it to be able to use your pool in the afternoons when it is sunny and warm.

If you require help sizing a heat pump for your pool please call us on 01322 554 870





Model

Heating Capacity At Air 26°C

Heat In Booster Mode Air 26°C

Max Pool Size (m3)

 Heating Capacity At Air 15°C

Heat In Booster Mode Air 15°C

GHD-150-0300

13.3kw

13.3kw

16kw

35-65 m3

9.7kw

11.74kw

GHD-150-0301

17kw

17kw

20.4kw

40-75 m3

12.5kw

15kw

GHD-150-0302

21.9kw

21.9kw 26.3kw 50-95m3 16kw 19kw
heatseeker inverter swimming pool heat pump

HeatSeeker Inverter Swimming Pool Heat Pump

by World of Pools.com
£1,595.00
  • HeatSeeker Inverter Heat Pumps For Swimming Pools
  • 4 New 2021 Models - 7.8kw to 21kw
  • Extended Summer Season Swimming Pool Heat Pump
  • Low Start Up Current - No Soft Start Required
  • Reverse Cycle Gas Defrost - 4 Way Valve
  • R32 Refrigerant Gas
  • ABS Shell
  • Ultra Quiet Operation.
  • 5 Year Warranty On Heat Exchanger - 2 Year Parts Warranty

DELIVERY: We aim to send HeatSeeker Inverter Heat Pumps out on a next working day service but all standard deliveries will be within 5 working days

RETURNS:

HeatSeeker Inverter Heat Pumps can be returned in original packaging, suitable for resale, within 14 days from date of delivery. Returns should be sent via a "Signed For" carrier or post.

Returns Address: Giraffe Enterprises Ltd, Bexley Garden Centre, 57 North Cray Road, Sidcup, Kent. DA14 5EU. Tel: 01322 554 870

When we receive the item, our returns department confirm that everything is present and in its in original condition to ensure its eligibility for refund. We process refunds as quickly as possible. We process most refunds on the same day which they were received, but please allow up to a maximum of 14 days for the money to reach your account. It rarely takes this long, but can happen sometimes for reasons such as bank delays or errors.

PRODUCT INFO:

Heatseeker Inverter Swimming Pool Heat Pumps new 2021 HSI range have been developed to compete with the very top end of the heat pump market.

The HeatSeeker Inverter is from the same manufacturer as the original “Heatseeker” so has been built with the same level of reliability and support associated with Plastica’s well established brand. The HeatSeeker inverter technology increases efficiency, whilst dramatically reducing start up current, so will not require the fitting of an additional soft start.

Heatseeker Inverter Swimming Pool Heat Pumps are one of the best performing heat pumps in the market. Unlike many other heat pumps available in the UK, the output of the Heatseeker Heat Pumps is based on 15 degrees Celsius air temp, which is a realistic temperature for the UK. Most other models including the Hydropro range calculate their output at 27 degrees which means their actual output at 15 degrees is dramatically less, as an example the Hydropro Inverter 17 and Heatseeker Inverter 12.5 produce approximately the same heat at 15 degrees Celsius. The Heatseeker Inverter Heat Pump offers an exceptionally efficient and cost effective means of heating pool water. Low running costs and an ultra quiet operation make the HeatSeeker Inverter and exceptional choice for your swimming pool heat pump.

An integral fan draws air across an evaporator, heat from the airflow is captured by the refrigerant flowing through the evaporator. Having extracted the heat from the air, the refrigerant is condensed and its heat then transferred to the passing pool water via the HeatSeekers heat exchanger.

Heat pump technology is reliable, environmentally friendly and extremely cost effective.

This sizing chart assumes that a pool is being heated from May to September, the desired pool temperature is 29 degrees C, the ambient air temperature is not less than 15OC and a heat retention cover is used. Although the HSI Range remains efficient down to 7 degrees C.

 HeatSeeker Inverter Model Type C MCB (A) Running Current (amps) Noise (1m & 3m) Net Weight Optimum Flow Rated Heating Output Max Pool Volume
HSI078 7.8kw 13 5.5 - 2.6 52-46dB 48kg 3.4m3/h 8.02kw - 4.09kw 25m3
HSI125 12.5kw 16 11.18 - 4.99 58-47dB 49kg 5.4m3/h 12.64kw - 7.86kw 50m3
HSI170 17KW 25 15.41 - 5.15 58-52dB 64kg 7.3m3/h 16.kw - 9.54kw 70m3
HSI210 21KW 32 17.82 - 7.5 58-52dB 89kg 9.0m3/h 23.48kw - 13.28kw 85m3

Plastica HeatSeeker Inverter Heat Pump Features :

  • Proven reliability
  • Ultra Quiet Operation
  • Titanium heat exchanger
  • High efficiency compressor
  • Self diagnostic
  • Fully programmable
  • Quick and easy installation
  • ABS Casing
  • Very quiet operation
  • Reverse cycle defrost
  • Soft start typically lowers start-up amps by at least 50%

If you would like help choosing which Heatseeker Inverter Heat Pump is most suitable for your swimming pool please call us on 01322 554 870. We will be more than happy to help.
